Universal dimmer with integrated push button – UL approved – White
Universal in-line dimmer in white finish, with integrated button and mains presence indicator LED. An elegant and discreet solution, ideal for bright spaces or lighting projects with a clean, modern character. Works with any type of lamp and includes minimum adjustment and additional end-of-life protection for the lamp.
Please note: max 4 dimmable lamps for cfl or led loads.
Technical specifications:
Universal in-line push-button dimmer
Size: 96.5 x 30.5 x 28 mm
Input voltage: 100-240V
Power range:
- 4-25W for dimmable LED light bulbs
- 4-100W @120V INC
- 4-150W @220-240V INC
- 11-25W for dimmable energy-saving light bulbs (CFL)
Ambient temperature: 35°C
Cable section: flat H03VVH2-F or round H03VV-F 2x0.75 mm²
Certification: UL
