EIVA-3 3-way IP65 joint for outdoor use - Modulair system - Black
EIVA-3 Black is the T-connector with IP65 protection rating from the Modulair outdoor range: the world’s first IP65 outdoor lighting system that can be wired, perfect for creating customised and bold installations. The special insulating gel inside guarantees total resistance to rain and storms, with an elegant and modern touch.
Easy and quick to assemble, EIVA-3 Black allows you to create numerous outdoor lighting configurations using the existing connections. The assembly is snap-fit, with no need for tools: you can create pendant lights with exposed light bulbs or with a lampshade, or arrange garlands in crossings to form a spectacular lattice of lights.
With EIVA-3 Black you have the freedom to choose the number, spacing and length of the pendant drops, bringing light wherever you wish. The upper ring allows you to attach the joint anywhere, from a pergola to a wall. In addition, the matching side cap included in the kit allows it to be used as an end piece, ensuring aesthetic consistency.
EIVA-3 Black is a product designed, engineered and produced by EIVA in Italy.
Technical specifications:
EIVA-3, 3-way outdoor connection:
Connection device for lighting equipment CE 60598-1
Material: thermoplastic, pre-filled with insulating gel
Height: 115mm
Width: 75mm
Thickness: 26mm
Rated voltage: 110/250 V ac
Compatible with H05RN-F 2x1mm2 cables
Class: II
Protection rating: IP65
Includes cable clamp, a silicone cap for side holes and a hook for ceiling mounting.
The maximum load supported by the wired cables is 1.5 kg.
